i3D Mobility | Mobility Designed Around Everyday Life Journal
Mobility guides, fitting advice, and engineering notes from the i3D team.
2 articles
Looking for a custom wheelchair designed around your individual needs? The I3D Carbon Custom range from i3D Mobility offers personalized wheelchair configurations…
Mobility is more than simply being able to move from one place to another. It is about independence, confidence, participation, dignity, and…
Compare the range
All dimensions exclude seat cushion. Specifications are indicative of i3D capability; precise fit can be achieved to a millimetre.
| Specification | 01 Aluminium Alloy | 02 Carbon Fibre | 03 Titanium | 04 Electric / Electric Assist |
|---|---|---|---|---|
| Price range — RRP (full custom) |
5k
|
13k
|
12k (foldable)
14k (rigid) |
NA
|
| Lead time |
16 weeks
|
16 weeks
|
16 weeks
|
8 weeks
|
| SPECS | ||||
| Max load |
120 kg
|
100 kg
|
150 kg
highest max weight
|
136 kg
|
| Fit type |
custom
|
custom
|
custom
|
standard
|
| Frame weight without wheels |
10 – 12 kg
|
7.5 – 8 kg
lightest
|
7.6 – 9 kg
mid-range
|
12 kg
without battery
15 kg (with battery) |
| Frame type |
foldable
|
foldable
|
rigid or foldable
|
foldable
|
| Frame material |
aluminium alloy
|
carbon fibre
|
titanium alloy
|
carbon fibre
|
| Side guard |
aluminium alloy
|
carbon fibre
|
carbon fibre
|
carbon fibre
|
| Seat panel |
aluminium alloy
|
carbon fibre
|
soft fabric
|
soft fabric
|
| Backrest |
aluminium alloy
|
carbon fibre
|
carbon fibre
|
soft fabric
|
| SEAT | ||||
| Seat width (cm) |
34 – 42
continuous range
|
34 – 42
continuous range
|
34 / 36 / 38 / 40 / 42 / 44
6 fixed options; widest at 44 cm
|
43.5
|
| Seat depth (cm) |
41 (std) / 45 (ext)
adjustable
|
40 – 46
adjustable range
|
38 / 40 / 42
3 fixed options
|
42.5
|
| Backrest height (cm) |
32 ± 2
|
30
|
35 / 37
highest backrest
|
48.8
|
| SEAT HEIGHT OPTIONS | ||||
| Front seat height (cm) |
Low: 45
Ext. Low: 46 High: 48 Ext. High: 49 |
Option 1: 43 ± 1
Option 2: 45 ± 1 Option 3: 47 ± 1 |
Low: 45.0
High: 47.5 |
51
|
| Rear seat height (cm) |
Low / Ext. Low: 37
High / Ext. High: 41 |
Option 1: 38 ± 1
Option 2: 40 ± 1 Option 3: 42 ± 1 |
Low: 40.0
High: 42.5 |
51
|
| WHEELS & TYRES | ||||
| Drive wheel size |
24-inch standard, 26-inch optional
|
24-inch standard, 26-inch optional
|
24-inch standard, 26-inch optional
|
8.5″ rear motor wheel
|
| Drive wheel rim |
Aluminium alloy
|
Carbon
3-spoke carbon wheel
|
aluminium alloy
|
no wheel rim
|
| Camber angle |
0°
|
0°
|
0° / 3°
the only model with a camber option
|
no camber angle
|
| Tyre |
24 × 1 black rubber
|
24 × 1 black rubber
|
24 × 1 black rubber
|
8.5″ PU tyre
|
| Front caster |
4-inch solid tyre, single- or double-arm fork
|
4-inch solid tyre, single- or double-arm fork
|
4-inch solid tyre, single- or double-arm fork
|
7″ PU tyre
|
| Centre of gravity |
3-gear system — aluminium & carbon fibre
Centre of gravity adjustment (additional $2000)
Gear 1: Anti-tipping Gear 2: Balanced stability/performance Gear 3: Easy wheelie operation |
3-gear system — aluminium & carbon fibre
Centre of gravity adjustment (additional $2000)
Gear 1: Anti-tipping Gear 2: Balanced stability/performance Gear 3: Easy wheelie operation |
3-gear system — aluminium & carbon fibre
Centre of gravity adjustment (additional $2000)
Gear 1: Anti-tipping Gear 2: Balanced stability/performance Gear 3: Easy wheelie operation |
NA
|
